Temperature Probes SUS 4 * 65mm Tube Heat Resistance Thermocouple Temperature Sensor PT100
NTC Temperature Sensor is widely used for kitchen appliance, air conditioning, home appliances,such as ice-box, air-conditioner system, refrigerator, office equipment, cars, industry
The wire materials can be made of PVC or TPE.
Model:2k, 5k, 10K, R25 degree C,
B25/85=3435K+-1%,B25/85=3470K+-1%,B25/85=3977K+-1%,
tolerance 0.1%~5%
The outlook and wire length and dimension can be made based on customer required
High Precision DS18B20 Digital Temperature Sensor Specification:
thermomolded IP 68 NTC 10K 1% B25/85 = 3435K 1% head SUS304 6x50mm black round cable ext diam.3mm double insulation 2x26AWG L=3000mm stripped 30mm and tinned ends 5mm. Temperature range -50/+120°C
Quick Details:
Place of Origin: | Jiangsu, China (Mainland) | Brand Name: | Retekool | Model Number: | s-sensor-1 |
Usage: | Temperature Sensor | Theory: | Resistance Sensor | Output: | Digital Sensor |
Resistance: | R25ºC=47KΩ±1% B25/50ºC=3950K±1% or Customized | Accuracy: | A, B class | Response Time: | 4S |
Shell Tpye: | TPE/OD=3.1mm(11×0.16mm )wire | Shell Size: | 6X50mm or as required | Connector: | As required |
Wire material: | Teflon or silicon wire | Wire Length: | 3000mm or as required | Temperature Range: | -50~120°C |
Packaging & Delivery:
Packaging Details: | Packed in strong poly bags, several bags packed in standard high press-resistance box. Each box will take 4 belt. And we will put the sticker of sensor specification attached. Box Size: 460*335*350mm or customized |
| Delivery Detail: | Within 20 workdays for first order, 10~15 workdays for repeat orders |
High Precision DS18B20 Digital Temperature Sensor
